DPM-C520

Delta’s Standard Multifunction Power Meter DPM-C520 is designed as a 3-phase high-precision smart power meter that fulfills the demand for monitoring the electricity data of multi-factories, and is suitable for installation on electric panels.

● Measures electric parameters and harmonics
● Supports alert and parameter group settings
● Adopts Modbus protocol, suitable for control system applications, SCADA systems, and energy management & monitoring systems

Product Introduction

Features & Benefits

High-precision Power Quality and Electricity Parameter Measurement

  • High-precision Class 0.5S bidirectional energy and electricity parameter measurement, complies with IEC 62053 and CNS 14607 criteria
  • Supports power quality measurement of total / individual harmonic distortion and current / voltage unbalance


Parameter Grouping Function

  • All electricity data can be combined as a parameter group that allows access for master controllers (including PLCs, SCADA and EMS). This function reduces reading time as well as enhances real-time data accessibility of the master controllers
  • Combines several discontinuous register addresses to one continuous address, reducing commands to achieve high-efficiency data acquisition of the master controllers (SCADA and PLC)

Simple Installation and Operation

  • The DPM-C520 adopts fixing clips on both sides of the meter for easy installation without requiring tools and screws
  • Supports the MODBUS protocol. All parameters can be transmitted to the master controllers via the built-in RS-485 communication interface

Applications



  • The DPM-C520 is suitable for: energy management, medium or low voltage distribution systems, smart switch cabinets, energy management systems, factory automation systems, building automation systems, railway energy management systems, electric heating systems, wind power systems, energy storage systems, electric grid measurement, and energy quality analysis.

Specifications
Model DPM-C530 DPM-C530E DPM-C532
Measurement Accuracy
Current ± 0.5%
Voltage ± 0.5%
Active Energy IEC 62053-22 Class 0.5S
Reactive Energy ± 1%
Apparent Energy ± 2%
Active Power ± 0.5%
Reactive Power ± 1%
Apparent Power ± 2%
Power Factor ± 0.5%
Frequency ± 0.5%
MID Directive EN50470-1,
EN50470-3		   Annex B and Annex D  Class C in DPM-C530EM Annex B and Annex D  Class C in DPM-C532M
Input Characteristics
Measuring System Type 1P2W, 1P3W, 3P3W, 3P4W
Voltage 35 Vac~ 690 Vac (L-L)
20 Vac~ 400 Vac (L-N)
Current 1 A / 5 A
Frequency 45 ~ 70 Hz
Control Power AC: 100 ~ 240 V  ( Max.Power Consumption 4.6 W)
DC: 100 ~ 300 V
I/O
Digital Input     4
Digital Output     2
Data Record
Max. / Min Log ● ● ●
Alarm Status & Timestamp ● ● ●
Alarm Counting ● ● ●
Alarm History Record 500 500 500
Data Logging Up to 17 parameters with configurable interval & duration (e.g. 17 parameters for 30 days at 1 minute interval)
Customizable Data Logs ● ● ●
Commnication
Protocol
( Interface)		 Modbus RTU / ASCII
（RS - 485）
BACnet MS/TP
(RS-485)		 Modbus TCP
(Ethernet)		 Modbus RTU / ASCII
（RS - 485）
BACnet MS/TP
(RS-485)
Mechanical Characteristics
IP Protection - Front display IP52
IP Protection - Meter body IP20
Dimensions (W xH x D, mm) 96*96*95.4 96*96*127.5 96*96*127.5
Weight (g) 400 450 450
Environmental Characteristics
Operating Temperature -20 ℃ ~ +60 ℃
Storage Temperature -30 ℃ ~ +70 ℃
Relative Humidty ~ 95% RH
Altitude  Below 2000 meters
Certification
Safety UL / CE / RCM UL / CE
Accuracy IEC 62053-22 / CMA IEC 62053-22 / CMA / EN50470-3 (DPM-C530EM/C532M)
